Underground Utility Locators

Compare The UtiliGuard 2 Series

Looking for the best underground utility locator equipment for your needs? Compare and contrast the complete UtiliGuard 2 Series in a quick glance.

Specifications/Features	UtiliGuard 2 Classic	UtiliGuard 2 Standard	UtiliGuard 2 Advanced	UtiliGuard 2 RTK
Number of Frequencies	70+	70+	70+	70+
UtiliGuard 2 Interface	✔	✔	✔	✔
Classic Interface	✔	✔	✔	✔
Compass	✔	✔	✔	✔
Frequencies/Settings Configurable	✔	✔	✔	✔
Total Field Antenna	✔	✔	✔	✔
Direction Enabled	✔	✔	✔	✔
Receiver Accessories Compatibility	✔	✔	✔	✔
Integrated GPS	✘	✔	✔	✔
External GPS Connectivity	✘	✔	✔	✔
Logging GPS Data on Receiver	✘	✔ (1 million log points)	✔ (1 million log points)	✔ (1 million log points)
Compatible with MyUtiliGuard™ App	✘	✔	✔	✔
Compatible with External Mapping Software	✘	✔	✔	✔
AIM® (Ambient Interference Measurement)	✘	✘	✘	✔
Offset Depth Measurement	✘	✘	✔	✔
RX/TX Communication and Range	✘	✘	✔	✔
Centimeter-Level Accuracy	✘	✘	✘	✔
RTK Technology	✘	✘	✘	✔

Locating Beacons

Whether you’re locating metallic pipe, non-metallic pipe or conduit, our utility locating beacons help you easily trace a path or locate blockages.

Offering frequencies of 512 Hz up to 33 kHz, our 150 conduit beacons provide a solution for every locating application and can be used with 150, 250, 910, 950 and UtiliGuard Locators. We also offer the 910B (512 Hz) and 11B (29.43 kHz) beacons, specifically designed for use in non-metallic pipe and easily attached to a flexible rod or pulled cable.

KEY FEATURES

Navigate 45°, 90° and 180° pipe joining up to 1.25″ in diameter with ease.
150 conduit beacons provide greater stability in straight pipe up to 1.25″ in diameter, due to longer design.
150 short-range conduit beacons can trace pipes at ranges up to 12 ft. through plastic pipe.
150 long-range conduit beacons have ranges up to 30 ft. through plastic pipe.
910B and 11B beacons easily attach to flexible rod or pull cable assembly for use in non-metallic or ductile iron (910B only) pipes.

Transmitter

The UtiliGuard 2 Series features four different transmitter options: T5, T5 Advanced, T12, T12 Advanced. Each transmitter option features over 70 preset frequencies, configuration software and allows you to choose your output.

Key Features

Remotely control the transmitter with the receiver.
12-watt transmitter drives signals farther down large, direct-buried utilities.
Transmitter connects to two utilities at once, reducing the time required to locate multiple services.

Utiliview: Mapping App

Take Mapping Data Straight From The Field To The Cloud.

The UtiliView app, when paired with the UtiliGuard 2 RTK, is like a direct conduit for your mapping data—sending it straight from the locator to your Esri™ mapping software with the push of a button. The process is simple and secure. With no customer data being collected along the way.

DOwnload Literature

Key Features

Compatible with Esri Cloud Services, allowing you to access and integrate your data anywhere.
Easily add photos to your log points, providing visual documentation for clearer, more complete records.
Save time and increase record accuracy by getting instant distance measurements on located lines when logging multiple points.
